BMW X4 – ENGINES, FACTS AND DIMENSIONS.
The key facts and figures for the BMW X4 at a glance: find out all about engines, consumption, CO2 emissions and dimensions of the various BMW X4 Range. Compare impressive performance data such as displacement, kW, Nm and acceleration – and discover which of these exceptional Sports Activity Coupés (SAC) suits you best.
ENGINES AND TECHNICAL DATA OF THE BMW X4 RANGE.
Select model
- BMW X4 xDrive20d
- BMW X4 M40i
No search result found. Please try another input
| Unladen weight in kg | 1,770 |
|---|---|
| Max. permissible weight in kg | 2,440 |
| Permitted load in kg | 670 |
| Permitted axle load front/rear in kg | 1,200/1,400 |
| Luggage capacity in l | 525 - 1430 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load (braked) in kg | 2,000 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW at 1/min | 140/4,000 |
| Engine torque (Nm) at 1/min | 400/1,750-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 213 |
|---|---|
| Acceleration 0–100 km/h in s | 8.0 |
| Combined in l/100 km | 5.6 |
|---|---|
| CO2 combined emissions in g/km | 147 |
| Tank capacity, approx. in l | 68 |
| Tyre dimensions front | 245/50 R19 |
|---|---|
| Tyre dimensions rear | 245/50 R19 |
| Wheel dimensions and material front | 7.5 J x 19 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 19 inches, light-alloy |
| Unladen weight in kg | 1,920 |
|---|---|
| Max. permissible weight in kg | 2,500 |
| Permitted load in kg | 580 |
| Permitted axle load front/rear in kg | 1,220/1,425 |
| Luggage capacity in l | 525 - 1430 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load (braked) in kg | 2,000 |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW at 1/min | 285/5,800-6,500 |
| Engine torque (Nm) at 1/min | 500/1,900-5,000 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 4.5 |
| Combined in l/100 km | 8.9 |
|---|---|
| CO2 combined emissions in g/km | 204 |
| Tank capacity, approx. in l | 65 |
| Tyre dimensions front | 245/40 R21 |
|---|---|
| Tyre dimensions rear | 275/35 R21 |
| Wheel dimensions and material front | 8.5 J x 21 inches, light-alloy |
| Wheel dimensions and material rear | 9.5 J x 21 inches, light-alloy |
Global shortages on standard and optional equipment.
Please note that certain standard and optional equipment may not be available on selected vehicles at present. Please check the listed features on your vehicle when placing your order and confirm the exact delivery date after placing the order with your preferred Retailer, as delays are possible.
FUEL CONSUMPTION AND CO2 EMISSIONS OF THE BMW X4.
BMW X4 xDrive20d:
Fuel consumption in l/100 km (combined): 5.6
CO2 emissions in g/km (combined): 147
BMW X4 M40i:
Fuel consumption in l/100 km (combined): 8.9
CO2 emissions in g/km (combined): 204
*The published fuel consumption and CO2 emission figures are established according to legislated technical specifications (UNECE Regulation 101/UN Regulation 83 and SANS 20101 standards), which sets out the procedures that are used to measure the CO2 emissions and fuel consumption. The claimed figures are established using specific tests under standardised, carefully controlled conditions and may differ from consumption achieved under real world conditions with the influences of altitude, road surface, geographic conditions, vehicle options, temperature, humidity, tyres size and driving behaviour amongst others. EU Unladen mass refers to a vehicle with standard equipment, with 90% fuel tank fill, including a driver (68 kg) and luggage (7 kg). Optional extras and accessories will generally increase this figure. Please contact your preferred authorized BMW dealer or BMW South Africa (Pty) Ltd. for information on vehicles that are available for sale, and the various specifications and options of vehicles that are available. Trailer loads may not exceed the load stated for un-braked or for braked trailer and the max tow bar load may not exceed the value stated. Vehicle heights are measured without the aerial. The heights are slightly higher if measured over the aerial. Measurements are stated for vehicles with standard fittings and may vary when optional equipment is fitted. The technical data stated refers to the current version of the model selected. Due to certain legal regulations in different countries, deviations in the technical data described here can occur.
