TECHNICAL DATA OF THE BMW X4.

Select model

Weight

Unladen weight EU in kg 1,875
Max. permissible weight in kg 2,420
Permitted load in kg 620
Permitted axle load front/rear in kg 1,160/1,400
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,400(1)-2,000
Trailer load 12% (braked) in kg 2,400(1)-2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 215
Acceleration 0–100 km/h in s 8.4-8.3

Fuel consumption

Combined in l/100 km 8.4-7.5
CO2 combined emissions in g/km 190-169
Tank capacity, approx. in l 65

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1,890
Max. permissible weight in kg 2,450
Permitted load in kg 635
Permitted axle load front/rear in kg 1,160/1,400
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,400(1)-2,000
Trailer load 12% (braked) in kg 2,400(1)-2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 180 (245)/5,000-6,500
Engine torque (Nm) at 1/min 350/1,560-4,800
Compression ratio : 1 10.2

Performance

Top speed in km/h 235
Acceleration 0–100 km/h in s 6.6

Fuel consumption

Combined in l/100 km 8.5-7.5
CO2 combined emissions in g/km 192-171
Tank capacity, approx. in l 65

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1,920
Max. permissible weight in kg 2,500
Permitted load in kg 580
Permitted axle load front/rear in kg 1,220/1,425
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,400(1)-2,000
Trailer load 12% (braked) in kg 2,400(1)-2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2.998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 265 (360)/5,200-6,500
Engine torque (Nm) at 1/min 500/1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.9

Fuel consumption

Combined in l/100 km 9.5-8.7
CO2 combined emissions in g/km 216-198
Tank capacity, approx. in l 65

Wheels

Tyre dimensions front 245/40 R21 103 W XL
Tyre dimensions rear 275/35 R21 106 W XL
Wheel dimensions and material front 8.5 J x 21 inches, light-alloy
Wheel dimensions and material rear 9.5 J x 21 inches, light-alloy

Weight

Unladen weight EU in kg -
Max. permissible weight in kg -
Permitted load in kg -
Permitted axle load front/rear in kg -
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,400(1)-2,000
Trailer load 12% (braked) in kg 2,400(1)-2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 120-140 (163-190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 205-213
Acceleration 0–100 km/h in s 9.0-7.9

Fuel consumption

Combined in l/100 km 6.5-5.7
CO2 combined emissions in g/km 170-149
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 2,010
Max. permissible weight in kg 2,530
Permitted load in kg 595
Permitted axle load front/rear in kg 1,220/1,415
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,400(1)-2,000
Trailer load 12% (braked) in kg 2,400(1)-2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 210 (286)/4,000
Engine torque (Nm) at 1/min 650/1,500-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 235-245
Acceleration 0–100 km/h in s 5.9-5.7

Fuel consumption

Combined in l/100 km 7.0-6.1
CO2 combined emissions in g/km 183-161
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 2,095
Max. permissible weight in kg 2,560
Permitted load in kg 540
Permitted axle load front/rear in kg 1,230/1,430
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,400(1)-2,000
Trailer load 12% (braked) in kg 2,400(1)-2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 250 (340)/4,400
Engine torque (Nm) at 1/min 700/1,750-2,250
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.9

Fuel consumption

Combined in l/100 km 7.3-6.5
CO2 combined emissions in g/km 191-171
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 245/45 R20 103 W XL
Tyre dimensions rear 275/40 R20 106 W XL
Wheel dimensions and material front 8 J x 20 inches, light-alloy
Wheel dimensions and material rear 9.5 J x 20 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions of the BMW X4.

BMW X4 xDrive30i:
Fuel consumption in l/100 km (combined): 8.5–7.9
CO2 emissions in g/km (combined): 193–171

BMW X4 M40i:
Fuel consumption in l/100 km (combined): 9.5–8.7
CO2 emissions in g/km (combined): 216–198


Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
