TECHNICAL DATA OF THE BMW 1 SERIES.

Select model
Select Transmission

Motor

Cylinder/ Valves per cylinder 3 / 4
Technical capacity in cm3 1,499
Stroke/Drilling in mm 94.6 / 82
Leistung des Verbrennermotors in kW (PS) 103 (140) / 4600-6500
Max torque(Nm) per 1/min 220 / 1480-4200
Compression:1 11

Performance

Top Speed 211
Acceleration 8.5

Measurements

Langth/Width/Height 4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2081 (1045 / 1036)
Wheelbase in mm/Wheel turn in m 2,670 / 11.4

Weight

Weight not loaded in kg 1,395
Weight Max in kg 1,870
Permitted load in kg 550
Permitted Axel load front/rear in kg 1,005 / 940
Allowed unbraked trailer load / drawbar load in kg 695 / 75
Allowed braked trailer load up to 12 % / 8 % incline in kg 1,300
Trunk capacity min.-max. in l 380 - 1200

Wheels

Tire front 205/55 R16 91 W
Tire rear 205/55 R16 91 W
Rim front 7Jx16 LM
Rim rear 7Jx16 LM

Consumption

Consumption urban in l/100km 7
Consumption non urban in l/100km 5.3
Consumption overall in l/100km 5.9
Co2 overall in g/km 135
Tank capacity in l 50
EU emission standard länderspezifisch

FUEL CONSUMPTION AND CO2 EMISSIONS OF THE BMW 1 SERIES.

BMW M135i xDrive:
Fuel consumption in l/100 km (combined): 7.5
CO2 emissions in g/km (combined): 171



BMW 128ti:
Fuel consumption in l/100 km (combined): 6.8
CO2 emissions in g/km (combined): 156



Images show optional equipment, screens and displays depend on equipment options.



The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval.



The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tyres available on the selected model.



The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable.



The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.
