BMW 1 Series, technical data

THE 1

BMW 1 SERIES: TECHNICAL DATA

THE 1BMW 1 SERIES: TECHNICAL DATA

TECHNICAL DATA OF THE BMW 1 SERIES.

Select model

Weight

Unladen weight EU in kg 1.395
Max. permissible weight in kg 1.87
Permitted load in kg 550
Permitted axle load front/rear in kg 1,005/940
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load 12% (braked) in kg 1,300
Trailer load (unbraked) in kg 695

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 103 /4,600-6,500
Engine torque (Nm) at 1/min 220/1,480-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 211
Acceleration 0–100 km/h in s 8.5

Fuel consumption

Combined in l/100 km 5,9
CO2 combined emissions in g/km 135
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 205/55 R16 91 W
Tyre dimensions rear 205/55 R16 91 W
Wheel dimensions and material front 7 J x 16 inches, steel
Wheel dimensions and material rear 7 J x 16 inches, steel

FUEL CONSUMPTION AND CO2 EMISSIONS OF THE BMW 1 SERIES.

BMW M135i xDrive:
Fuel consumption in l/100 km (combined): 7.5
CO2 emissions in g/km (combined): 171



BMW 128ti:
Fuel consumption in l/100 km (combined): 6.8
CO2 emissions in g/km (combined): 156



Images show optional equipment, screens and displays depend on equipment options.



The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval.



The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tyres available on the selected model.



The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable.



The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.
