BMW 5 Series Sedan (G60): Engines & technical data

TECHNICAL DATA FOR THE BMW 5 SERIES SEDAN.


Powertrain type	Electric

²
Powertrain type	Diesel – 48 Volt Mild-Hybrid
Power in kW	145
Torque in Nm	400
Transmission	8-speed, automatic

²
Cylinders	4
Displacement in cm³	1,995
Nominal power in kW/1/min	145
Nominal torque in Nm/1/min	400 / 1,500 - 2,750


Acceleration 0–100 km/h in s	7.3
Top speed in km/h	233

²
Fuel consumption in l/100 km	5.6
CO2 emissions in g/km	147

¹
Battery capacity in kWh	0.9


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156
Wheelbase in mm	2,995
Curb weight in kg ³	1,775
Gross Vehicle Mass (GVM) (kg)	2,405
Permitted load (kg)	630
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	2,000 / 100
Luggage capacity in l	520
Tank capacity in l	60

²
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW	190
Torque in Nm	400
Transmission	8-speed, automatic

²
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW/1/min	190
Nominal torque in Nm/1/min	400 / 1,600 - 4,500


Acceleration 0–100 km/h in s	6.2
Top speed in km/h	250

²
Fuel consumption in l/100 km	7.1
CO2 emissions in g/km	161

¹
Battery capacity in kWh	0.9


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156
Wheelbase in mm	2,995
Curb weight in kg ³	1,700
Gross Vehicle Mass (GVM) (kg)	2,340
Permitted load (kg)	640
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	2,000 / 100
Luggage capacity in l	520
Tank capacity in l	60


Powertrain type	Electric
Power in kW	442
Torque in Nm	795
Transmission	1-speed, automatic
Drivetrain	All-wheel drive


Acceleration 0–100 km/h in s	3.8
Top speed in km/h	230
Electric top speed in km/h	230


CO2 emissions in g/km	0
Fuel consumption in kWh/100 km	19.5–17.1
Electric range in km ⁵	472–540

¹
Battery capacity in kWh	81.2


5,060 mm
1,900 mm
1,505 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,505
Width incl. mirrors (driver / passenger side) in mm	2,156
Wheelbase in mm	2,995
Curb weight in kg ³	2,305
Gross Vehicle Mass (GVM) (kg)	2,895
Permitted load (kg)	590
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	2,000 / 80
Luggage capacity in l	490

²
Powertrain type	Petrol
Power in kW	153 (208) ⁶
Torque in Nm	330 ⁶
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

²
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW/1/min	140 (190)/4,400–6,500
Nominal torque in Nm/1/min	– /1,500–4,000


Acceleration 0–100 km/h in s	7.5
Top speed in km/h	230

²
Fuel consumption in l/100 km	6.4–5.8
CO2 emissions in g/km	144 - 130
Pass-by noise in dB(A)	67 ⁷
Stationary noise level in dB(A) / 1/min	73/3,750 ⁷


Battery capacity in kWh	0.9


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156 (1,081/1,075)
Wheelbase in mm	2,995
Curb weight in kg ³	1,800
Gross Vehicle Mass (GVM) (kg)	2,335
Permitted load (kg)	610
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	2,000 / 100
Luggage capacity in l	520
Tank capacity in l	60

²
Powertrain type	Diesel – 48 Volt Mild-Hybrid
Power in kW	223 (303) ⁸
Torque in Nm	670 ⁸
Transmission	8-speed, automatic
Drivetrain	All-wheel drive

²
Cylinders	6
Displacement in cm³	2,993
Nominal power in kW/1/min	210 (286)/4,000
Nominal torque in Nm/1/min	650/1,500–2,500


Acceleration 0–100 km/h in s	5.2
Top speed in km/h	250

²
Fuel consumption in l/100 km	6.3–5.8
CO2 emissions in g/km	165–152
Pass-by noise in dB(A)	65 ⁷
Stationary noise level in dB(A) / 1/min	73/3,000 ⁷

¹
Battery capacity in kWh	0.9


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156
Wheelbase in mm	2,995
Curb weight in kg ³	1,980
Gross Vehicle Mass (GVM) (kg)	2,560
Permitted load (kg)	655
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	2,000 / 100
Luggage capacity in l	520
Tank capacity in l	60


Powertrain type	Electric
Power in kW	250
Torque in Nm	400
Transmission	1-speed, automatic


Acceleration 0–100 km/h in s	6
Electric top speed in km/h	193


CO2 emissions in g/km	0
Fuel consumption in kWh/100 km	18–14.7
Electric range in km ⁵	512–627

¹
Battery capacity in kWh	81.2


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156
Wheelbase in mm	2,995
Curb weight in kg ³	2,130
Gross Vehicle Mass (GVM) (kg)	2,740
Permitted load (kg)	610
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	1,500 / 80
Luggage capacity in l	490

²
Powertrain type	Diesel – 48 Volt Mild-Hybrid
Power in kW	145 (197)
Torque in Nm	400
Transmission	8-speed, automatic
Drivetrain	All-wheel drive

²
Cylinders	4
Displacement in cm³	1,995
Nominal power in kW/1/min	145 (197) / 4,000
Nominal torque in Nm/1/min	400 / 1,500 - 2,750


Acceleration 0–100 km/h in s	7.3
Top speed in km/h	228

²
Fuel consumption in l/100 km	6–5.5
CO2 emissions in g/km	157–144
Pass-by noise in dB(A)	67 ⁷
Stationary noise level in dB(A) / 1/min	71 / 3,000 ⁷

¹
Battery capacity in kWh	0.9


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156
Wheelbase in mm	2,995
Curb weight in kg ³	1,905
Gross Vehicle Mass (GVM) (kg)	2,460
Permitted load (kg)	630
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	2,000 / 100
Luggage capacity in l	520
Tank capacity in l	60

^{2 ,}⁹
Powertrain type	Petrol – Plug-in-Hybrid
Power in kW	220 (299) ¹⁰
Torque in Nm	450 ¹⁰
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

²
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW/1/min	140 (190) / 4,400 - 6,500
Nominal torque in Nm/1/min	310 / 1,500 - 4,000


Acceleration 0–100 km/h in s	6.4
Top speed in km/h	230
Electric top speed in km/h	140

²
Fuel consumption in l/100 km ¹²	0.8 - 0.6
CO2 emissions in g/km ¹²	19 - 14
Fuel consumption in kWh/100 km ¹²	21.4 - 18.9
Electric range in km ⁵	87 - 102

¹
Battery capacity in kWh	19.4


5,060 mm
1,900 mm
1,515 mm
Length in mm	5,060
Width in mm	1,900
Height in mm	1,515
Width incl. mirrors (driver / passenger side) in mm	2,156 (1,081 / 1,075)
Wheelbase in mm	2,995
Curb weight in kg ³	2,080
Gross Vehicle Mass (GVM) (kg)	2,655
Permitted load (kg)	650
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	1,800 / 100
Luggage capacity in l	520
Tank capacity in l	60

1 The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

2 The published fuel consumption and CO2 emission figures are established according to legislated technical specifications (UNECE Regulation 101/UN Regulation 83 and SANS 20101 standards), which sets out the procedures that are used to measure the CO2 emissions and fuel consumption. The claimed figures are established using specific tests under standardised, carefully controlled conditions and may differ from consumption achieved under real world conditions with the influences of altitude, road surface, geographic conditions, vehicle options, temperature, humidity, tyres size and driving behaviour amongst others

3 EU Unladen mass refers to a vehicle with standard equipment, with 90% fuel tank fill, including a driver (68 kg) and luggage (7 kg). Optional extras and accessories will generally increase this figure.

4 Trailer loads may not exceed the load stated for un-braked or for braked trailer and the max tow bar load may not exceed the value stated

5 Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.

6 Depending on the environmental conditions, a temporary power boost adding approx. 10% to the max. output can be provided. The length of time that the peak output is available increases with falling ambient temperature (approx. 5 s at +25 °C, approx. 40 s at -20 °C).

7 Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 1151/2017.Unleaded RON 91 and higher with a maximum ethanol content of 25% (E25) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

8 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value).

9 For plug-in hybrid: Electric drive depending on battery charging level.

10 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value). Electric drive depending on battery charging level.

11 For plug-in hybrid: At temperatures below freezing, the fully electric drive system is only available after a few kilometres of driving, once the battery has heated to operational temperature.

12 For plug-in hybrid: Weighted, combined (EC AC Charge Weighted)

Fuel consumption and CO2 emissions.

BMW 520d ^[1]: Fuel consumption, combined WLTP in l/100 km: 5.6–5.1; CO2 emissions, combined WLTP in g/km: 147–133

^[1]Preliminary values
