BMW 1 Series 128ti F40, three-quarter rear view driving

THE 1

BMW 1 SERIES: ENGINES & TECHNICAL DATA.

Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW 1 Series.

Read more
THE 1BMW 1 SERIES: ENGINES & TECHNICAL DATA.

BMW 1 SERIES: TECHNICAL DATA.

Select model

Weight

Unladen weight in kg 1,320
Max. permissible weight in kg 1,870
Permitted load in kg 550
Permitted axle load front/rear in kg 1,005/940
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load (unbraked) in kg 695
Trailer load (braked) in kg 1,300

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 103/4,600-6,500
Engine torque (Nm) at 1/min 220/1,480-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 211
Acceleration 0–100 km/h in s 8.5

Fuel consumption

Combined in l/100 km 5.9
CO2 combined emissions in g/km 135
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 205/55 R16
Tyre dimensions rear 205/55 R16
Wheel dimensions and material front 7 J x 16 inches, light-alloy
Wheel dimensions and material rear 7 J x 16 inches, light-alloy

Weight

Unladen weight in kg 1,430
Max. permissible weight in kg 1,980
Permitted load in kg 550
Permitted axle load front/rear in kg 1,080/980
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load (unbraked) in kg 750
Trailer load (braked) in kg 1,300

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 110/4,000
Engine torque (Nm) at 1/min 380/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 214
Acceleration 0–100 km/h in s 8.4

Fuel consumption

Combined in l/100 km 4.7
CO2 combined emissions in g/km 123
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 205/55 R16
Tyre dimensions rear 205/55 R16
Wheel dimensions and material front 7 J x 16 inches, light-alloy
Wheel dimensions and material rear 7 J x 16 inches, light-alloy

Weight

Unladen weight in kg 1,440
Max. permissible weight in kg 2,000
Permitted load in kg 560
Permitted axle load front/rear in kg 1,085/990
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load (unbraked) in kg -
Trailer load (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 180/5,000-6,500
Engine torque (Nm) at 1/min 380/1,500-4,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 243
Acceleration 0–100 km/h in s 6.3

Fuel consumption

Combined in l/100 km 6.8
CO2 combined emissions in g/km 156
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/40 R18
Tyre dimensions rear 225/40 R18
Wheel dimensions and material front 8 J x 18 inches, light-alloy
Wheel dimensions and material rear 8 J x 18 inches, light-alloy

Weight

Unladen weight in kg 1,525
Max. permissible weight in kg 2,085
Permitted load in kg 560
Permitted axle load front/rear in kg 1,120/1,020
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load (unbraked) in kg -
Trailer load (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 225/5,000-6,250
Engine torque (Nm) at 1/min 450/1,750-4,500
Compression ratio : 1 9.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.8

Fuel consumption

Combined in l/100 km 7.5
CO2 combined emissions in g/km 170
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/40 R18
Tyre dimensions rear 225/40 R18
Wheel dimensions and material front 8 J x 18 inches, light-alloy
Wheel dimensions and material rear 8 J x 18 inches, light-alloy

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 118i:
Fuel consumption in l/100 km (combined): 5.9
CO2 emissions in g/km (combined): 135

BMW 118d:
Fuel consumption in l/100 km (combined): 4.7
CO2 emissions in g/km (combined): 123



BMW 128ti:
Fuel consumption in l/100 km (combined): 6.8
CO2 emissions in g/km (combined): 156

BMW M135i xDrive:
Fuel consumption in l/100 km (combined): 7.5
CO2 emissions in g/km (combined): 170



*The published fuel consumption and CO2 emission figures are established according to legislated technical specifications (UNECE Regulation 101/UN Regulation 83 and SANS 20101 standards), which sets out the procedures that are used to measure the CO2 emissions and fuel consumption. The claimed figures are established using specific tests under standardised, carefully controlled conditions and may differ from consumption achieved under real world conditions with the influences of altitude, road surface, geographic conditions, vehicle options, temperature, humidity, tyres size and driving behaviour amongst others. EU Unladen mass refers to a vehicle with standard equipment, with 90% fuel tank fill, including a driver (68 kg) and luggage (7 kg). Optional extras and accessories will generally increase this figure. Please contact your preferred authorized BMW dealer or BMW South Africa (Pty) Ltd. for information on vehicles that are available for sale, and the various specifications and options of vehicles that are available. Trailer loads may not exceed the load stated for un-braked or for braked trailer and the max tow bar load may not exceed the value stated. Vehicle heights are measured without the aerial. The heights are slightly higher if measured over the aerial. Measurements are stated for vehicles with standard fittings and may vary when optional equipment is fitted. The technical data stated refers to the current version of the model selected. Due to certain legal regulations in different countries, deviations in the technical data described here can occur.
